Specifications
1.8 10/100M RJ45 ports
2.Full Duplex and half-duplex mode
3.IP178G chipset
4.Plastic case
5.OEM/ODM offer
Feature:
Complies with IEEE 802.3, IEEE 802.3u standards
5 10/100Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode
Supports MAC address auto-learning and auto-aging
LED indicators for monitoring power, link, activity
Plastic case, desktop
External Power Adapter supply
Standards | IEEE802.3 10Base-T Ethernet
IEEE802.3u 100Base-TX Fast Ethernet
ANSI/IEEE 802.3 Nway Auto-Negotiation
IEEE802.3x Flow control |
Chipset | IP178G |
Frame filtering and forward rate | 10Mbps: 14880pps, 100Mbps: 148800pps |
Switching capacity | 1G |
Protocol | CSMA/CD |
Transfer method | Store-and-forward |
MAC address learning | Automatically learning, automatically Update |
Network media(Cable) | 10Base-T:2-Pair UTP category 3, 4, 5,5e,6 cable (maximum 100m),
EIA/TIA-568 100Ù STP(maximum 100m),
100Base-Tx: UTP category 5, 5e cable (maximum 100m),
EIA/TIA-568 100Ù STP (maximum 100m) |
Environment | Operating temperature: 0°C~40°C(32 F~104 F),
Storage temperature: -40°C~70°C(-40 F~158 F),
Operating humidity: 10%~90% non-condensing,
Storage humidity: 5%~90% non-condensing |
