Description:
The Fast Ethernet Switch provides 8 10/100/1000Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function,
eliminating the need for crossover cables or Uplink ports. The Switch is Plug and-Play and each port can be used as general
ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable.
Features:
Complies with IEEE802.3, IEEE802.3u standards.
8 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX.
Supports IEEE802.3x flow control for Full Duplex mode and back pressure for half-duplex mode.
Supports MAC address auto-learning and auto-aging.
LED indicators for monitoring power, link, activity.
External Power adapter 5VDC/1A
Desktop model , Metal case
Specification:
Interface: 8 10/100/1000/Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Power Input: 5VDC /1A
Transfer Method:Store and Forward
Advanced Functions:Green Technology, saving power up to70%
802.3X Flow Control, Back Pressure
Auto-Uplink Every Port
Package Contents: 8-Port 10/100/1000Mbps Desktop Switch
Power Adapter
User Guide
